Aluminum 5" Storz Cap with Cable

  •
1 9
Price: $152.38
$0.00 $152.38
Sale Sold out

Stock Level: 10 or more

Product Status: In Stock

When Will it Ship:

Shipping Cost: Free Shipping

Shipping Transit Time: 2 to 5 Business Days

Eligible for Express Shipping: Yes

Stock Level Updated: Dec 12, 2025


Item Number: SC5-D
Weight: 3.5 lb
View full details

Description

Aluminum storz cap with cable. Machined from forged 6061 - T6 aluminum. Hard coat anodized components per MIL-A-8625 Type III Class 1. Buna-N gaskets to resist most hydrocarbons, oils, gasoline, acids and greases. Complies with DIN standards which require that Storz heads must be forged when used in firefighting applications.

A Storz fitting enables a quarter turn sexless connection, no female or male side, with another Storz fitting. Connection features hooks and flanges with seal made by built-in included gaskets.

The Safe Water Drinking Act section 1417 requires "Lead-Free" products to be a minimum of 99.75% lead-free.

Specifications

  • Made in USA
  • Cap Size: 5 inches (125mm)
  • Material: Aluminum
  • Cable Length: 18 inches
  • Locking Cap: YES
  • Maximum Operating Pressure: 150 PSI
  • This cap will only connect to another 5 inch storz fitting
  • Gasket Pressure

1" (25mm) Storz Adapter

  • Inside Distance Between Lugs - 1 7/32" (31mm)
  • Number of Lugs - 2

1 1/2" (38mm) Storz Adapter

  • Inside Distance Between Lugs - 2 1/16" (52mm)
  • Number of Lugs - 2

2" (50mm) Storz Adapter

  • Inside Distance Between Lugs - 2 5/8" (66mm)
  • Number of Lugs - 2

2 1/2" (65mm) Storz Adapter

  • Inside Distance Between Lugs - 3 3/16" (81mm)
  • Number of Lugs - 2

3" (75mm) Storz Adapter

  • Inside Distance Between Lugs - 3 1/2" (89mm)
  • Number of Lugs - 2

4" (100mm) Storz Adapter

  • Inside Distance Between Lugs - 4 1/2" (115mm)
  • Number of Lugs - 2

5" (125mm) Storz Adapter

  • Inside Distance Between Lugs - 5 13/16" (148mm)
  • Number of Lugs - 2

6" (150mm) Storz Adapter

  • Inside Distance Between Lugs - 6.29" (160mm)
  • Number of Lugs - 3
