Green 1 1/2" x 20' Thread / Thread Suction Hose

  • Green 1 1/2" x 20' Thread / Thread Suction Hose
1 6
Price: $87.25
$0.00 $87.25
Sale Sold out

Stock Level: 5

Product Status: Limited Stock

When Will it Ship:

Shipping Cost: Free on orders over $100

Shipping Transit Time: 2 to 5 Business Days

Eligible for Express Shipping: Yes

Stock Level Updated: Nov 23, 2024


Item Number: 15HS20PPG
Weight: 14.0 lb

View full details

Description

Green lightweight pvc water suction hose is rated for medium duty. Reinforced with high tensile synthetic yarn and steel helix wire.

Applications

  • General purpose
  • Agricultural
  • Irrigation
  • Construction

Warning - Not intended for hydrant pressure or head pressure from an above ground holding tank



Specifications

  • Suction Hose Length: 20 feet
  • Male Coupling: Aluminum 1 1/2 inch NPT
  • Female Coupling: Brass 1 1/2 inch NPSH
  • The Male Coupling Will Only Connect to a Female 1 1/2 inch NPSH, or NPSM threads
  • The Female Coupling Will Only Connect to a Male 1 1/2 inch NPSH, NPT or NPSM threads
  • Approx. Bend Radius: 7 inch at 68°
  • Weight Per Foot: 0.37 pounds
  • Working Temperature: 0° F to 158° F
  • Hose ID: 1 1/2 inches
  • Hose OD: 1 3/4 inches
  • Vacuum Rating: 29" Hg @ 68°, 24" HG at 104°

1 1/2" Hose Male Coupling

  • Inside diameter of a male adapter: 1 1/2 inches
  • Outside diameter a male NPSH or NPT adapter: 1 7/8 inches (1.87) - 11.5 Threads per inch

Help Me Connect

Connections

  • The female side of a NH / NST coupling will only connect to a male NH / NST connection
  • The male side of a NH / NST coupling will only connect to a female NH / NST connection
  • The female side of a NPSH coupling will only connect to a male NPT pipe or a male NPSH connection
  • The male side of a NPSH coupling will only connect to a female NPSH connection.It will NOT thread into a female NPT pipe. For example, a male NPSH coupling will NOT thread into a female metal or pvc pipe.
  • The female side of a garden hose will only connect to a male garden hose connection.
  • The male side of a garden hose will only connect to a female garden hose connection.

The most common thread type in use by fire departments today is NST or National Standard Thread. NST also goes by the initials NH or National Hose. It can even be referred to as NHT or National Hose Thread but NST or NH is more common these days. NH = NST



Warranty Information

Limited 1-Year Warranty

We will replace any fire hose with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

Fire hoses purchased for use at Fire Training Facilities will have a 90-day Manufacturer Defect warranty only.

Upon receipt of the returned goods, hoses will be subject to inspection and testing.

Should it be determined that the hose is covered by warranty, it will be repaired or replaced.
