White 1" x 50' Single Jacket Hose (Alum NPSH Couplings)

Item Number: 10S550P
  • White 1" x 50' Single Jacket Hose (Alum NPSH Couplings)
1 9
$159.80
$0.00 $159.80
Sale Sold out
In Stock (10 or more)
Ships
Estimated transit time: 2 to 5 Business Days Eligible for Express Shipping

Free Shipping

Help Me Connect

NH / NST: The most common thread type in use by fire departments today is NST or National Standard Thread. NST also goes by the initials NH or National Hose. It can even be referred to as NHT or National Hose Thread but NST or NH is more common these days. NH = NST.

  • The female side of a NH / NST coupling will only connect to a male NH / NST connection
  • The male side of a NH / NST coupling will only connect to a female NH / NST connection

NPSH: National Pipe Straight Hose (NPSH) or Iron Pipe Thread (IPT) has the same threads per inch (TPI) as National Pipe Tapered (NPT) but the thread does not taper. NPSH is a straight thread and seals by a gasket in the female coupling which allows for a swivel, just like NH / NST, which make both ideal for hose couplings.

  • The female side of a NPSH coupling will only connect to a male NPT pipe or a male NPSH connection
  • The male side of a NPSH coupling will only connect to a female NPSH connection
  • It will NOT thread into a female NPT pipe. For example, a male NPSH coupling will NOT thread into a female metal or pvc pipe.

NPT: National Pipe Tapered is common in plumbing and some industrial uses. Sometimes referred to as pipe thread because PVC pipe and schedule 40 pipe are typically threaded in NPT. As its name implies this is a tapered thread so that the outside diameter of the male (ODM) gets smaller towards the end of the fitting and the inside diameter of the female narrows with depth. As the two fittings are threaded together the opposite tapers force thread friction and makes the seal without the use of a gasket.

Warranty Information

Any hose found to be defective due to materials and / or workmanship shall be replaced at no charge up to ten years. In general, hose warranties cover manufacturing defects leading to hose failure. Wear through and abuse are not covered by warranty.
View full details

Additional Details

Our 1 inch Made in USA single jacket fire hose is manufactured to meet and exceed all performance requirements of NFPA 1961. Jacket is tightly woven with ring spun polyester warp yarn with filament polyester fill yarn and is mildew resistant. Features EPDM synthetic rubber lining with excellent ozone, UV and aging resistance compared to SBR.

How To Purchase Fire Hose

  • Always ask where the hose is manufactured - Buy American!
  • Adding color impregnation improves durability and mildew resistance compared to untreated white hose
  • 50 foot lengths are easier to handle and offer more layout flexibility vs. 100 foot lengths
  • The most common hose, thread and couplings in use by fire departments today is double jacket hose with aluminum NH / NST
  • Double jacket hose with any color treatment is the most durable hose available

Applications

  • Light Industrial Use
  • Residential Use
  • Forest firefighting
  • Brush firefighting
  • Wildland firefighting

Test Ratings (Water Only With Expansion Ring Couplings)

  • Service Pressure (A 3-minute hydrostatic test conducted by users on in-service hose to determine suitability for continued service)
  • Proof Test Pressure (A pressure equal to a least two times the service test pressure)
  • PSI Burst Test Pressure



Specifications

  • Made in USA
  • Hose Size: 1 inch (Inside Diameter)
  • Hose Length: 50 feet (Approximately)
  • Male Coupling: Aluminum 1 inch NPSH
  • Swivel Female Coupling: Aluminum 1 inch NPSH
  • The Female Coupling Will Only Connect to a Male 1 inch NPT or NPSH
  • Compatible Nozzle: 1 inch NPSH only
  • Hose Type: Polyester Single Jacket (Mildew Resistant)
  • Color: White
  • Liner: EPDM Rubber
  • Approximate Width Laying Flat: 1 3/4 inches
  • Service Pressure: 300 PSI
  • Proof Test Pressure: 600 PSI
  • Burst Test Pressure: 900 PSI
  • UL Listed

1" Hose Male Couplings

  • Inside diameter of a male coupling: 1 inch
  • Outside diameter of a male NH / NST coupling: 1 3/8 inches (8 Threads per inch)
  • Outside diameter a male NPSH or NPT coupling: 1 5/16 inches (11.5 Threads per inch)

Download Spec Sheet
