White - Clear 4" x 20' Camlock Suction Hose

Item Number: 40HS20CE
  • White - Clear 4" x 20' Camlock Suction Hose
1 6
$223.43
$223.43
Sale Sold out
Special Order
Ships: Approx. Aug 17, 2026
Estimated transit time: 2 to 5 Business Days

Shipping Cost: Freight Charge $250 (Per Order)

Warranty Information

Limited 90-Day Warranty

We will replace any hose with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

Upon receipt of the returned goods, hoses will be subject to inspection and testing.

Should it be determined that the hose is covered by warranty, it will be repaired or replaced.



View full details

Additional Details

Our durable PVC hard suction hose is assembled in the USA. Clear side wall allows visual check of water flow. Lightweight camlock pvc water suction hose is rated for medium duty. Reinforced with high tensile synthetic yarn and steel helix wire.

Applications

  • General purpose
  • Agricultural
  • Irrigation
  • Construction

Camlock fittings (quick connect couplings) allow for quick, secure connections of hoses to tanks or other hoses. The name "Cam Lock" comes from the cam or lever that is used to lock one hose or fitting into place with another one. The female connector has two cams as part of the assembly. The male connector has a shape that allows the cams to lock into place. These couplings mate quickly and conveniently by inserting the grooved coupling into the cam coupling and simply closing the cam arms. Safety pins prevent the cam arms from accidental disconnection during use.

Warning: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer/birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov



Specifications

  • Suction Hose Length: 20 feet
  • Male Coupling: 4 inch global type "E" shank aluminum
  • Female Coupling: 4 inch global type "C" shank aluminum
  • Approx. Bend Radius: 15" at 68°
  • Weight Per Foot: 1.85 pounds
  • Working Temperature: 140° F down to -13° F
  • Hose ID: 4 inches
  • Hose OD: 4 1/2 inches
  • Vacuum Rating: 28" Hg @ 68°, 24" HG at 104°
  • Additional Handling or Freight Charge: See Shopping Cart
  • Multiple unit orders incur only 1 freight fee or oversize charge
  • Commercial Address Required for Freight Delivery

Male Camlock Dimensions

  • Size: 4 inches (4.00)
  • Male Outside Diameter: 4 3/4 inches (4.724)

Female Camlock Dimensions

  • Size: 4 inches (4.00)
  • Female Inside Diameter: 4 3/4 inches (4.763)
