White - Clear 6" x 20' Camlock Suction Hose

Skip to product information
1 of 5
Regular price Price: $384.98
Regular price Sale price $384.98
Sale Sold out

Stock Level: 0

Product Status: Special Order

When Will it Ship: Contact for Lead Time

Shipping Cost: Freight Charge $250 (Per Order)

Shipping Transit Time: 2 to 5 Business Days

Eligible for Express Shipping: No

Stock Level Updated: Dec 26, 2024


Item Number: 60HS20CE
Weight: 80.0 lb
View full details

Collapsible content

Description

Our durable PVC hard suction hose is assembled in the USA. Clear side wall allows visual check of water flow. Lightweight camlock pvc water suction hose is rated for medium duty. Reinforced with high tensile synthetic yarn and steel helix wire.

Applications

  • General purpose
  • Agricultural
  • Irrigation
  • Construction

Camlock fittings (quick connect couplings) allow for quick, secure connections of hoses to tanks or other hoses. The name "Cam Lock" comes from the cam or lever that is used to lock one hose or fitting into place with another one. The female connector has two cams as part of the assembly. The male connector has a shape that allows the cams to lock into place. These couplings mate quickly and conveniently by inserting the grooved coupling into the cam coupling and simply closing the cam arms. Safety pins prevent the cam arms from accidental disconnection during use.

Warning: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer/birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Specifications

  • Suction Hose Length: 20 feet
  • Male Coupling: 6 inch global type "E" shank aluminum
  • Female Coupling: 6 inch global type "C" shank aluminum
  • Approx. Bend Radius: 25" at 68°
  • Weight Per Foot: 3.70 pounds
  • Working Temperature: 140° F down to -13° F
  • Hose ID: 6 inches
  • Hose OD: 6.67 inches
  • Vacuum Rating: 28" Hg @ 68°, 24" HG at 104°
  • Additional Handling or Freight Charge - See Shopping Cart
  • Multiple unit orders incur only 1 freight fee or oversize charge
  • Commercial Address Required for Freight Delivery

Male Camlock Dimensions

  • Size: 6” (6.00)
  • Male Outside Diameter: 6 15/16” (6.920)

Female Camlock Dimensions

  • Size: 6 inches (6.00)
  • Female Inside Diameter: 7 inches (6.970)

Warranty Information

Limited 90-Day Warranty

We will replace any hose with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

Upon receipt of the returned goods, hoses will be subject to inspection and testing.

Should it be determined that the hose is covered by warranty, it will be repaired or replaced.
