Yellow 1" x 100' Forestry Hose (Alum NPSH Couplings) - Import

price:
Price
$173.82
Item Number: G10F6100PYL
Weight: 10.45 lb

Stock Level: 10 or more

Product Status: In Stock

When Will it Ship:

Shipping Cost: Free Shipping

Shipping Transit Time: 2 to 3 Business Days

Eligible for Express Shipping: Yes

Stock Level Updated: Apr 15, 2024


Our imported 1 inch yellow forestry fire hose with aluminum NPSH threaded couplings is manufactured to meet and exceed all performance requirements of NFPA 1961 and USDA 5100-187c Type II also known as US Forestry Service Specification 5100-187c Type II or FSS 5100-187c Type II. Meets or exceeds ULC-S518.1-11.

Polymer yellow coating improves durability over uncoated white Type I forestry hose and increases mildew resistance...no drying necessary.

This wildland fire hose features a TPU (polyurethane) lining to reduce friction loss and deliver more water. The TPU lining also reduces weight and allows the hose to pack flat for easy transport. Hose remains flexible to -65 degrees F (-45 degrees C).

NSN 4210-01-526-3000 NFES 0932

How To Purchase Fire Hose

  • Adding color impregnation improves durability and mildew resistance compared to untreated white hose
  • 50 foot lengths are easier to handle and offer more layout flexibility vs. 100 foot lengths

Applications

  • Forest firefighting
  • Brush firefighting
  • Wildland firefighting
  • Light Industrial Use
  • Residential Use

Test Ratings (Water Only With Expansion Ring Couplings)

  • Service Pressure (A 3-minute hydrostatic test conducted by users on in-service hose to determine suitability for continued service)
  • Proof Test Pressure (A pressure equal to a least two times the service test pressure)
  • PSI Burst Test Pressure
  • Imported
  • Hose Size - 1 inch (Inside Diameter)
  • Hose Length - 100 feet (Approximately)
  • Male Coupling - Aluminum 1 inch NPSH
  • Swivel Female Coupling - Aluminum 1 inch NPSH
  • The Female Coupling Will Only Connect to a Male 1 inch NPT or NPSH
  • Compatible Nozzle - 1 inch NPSH only
  • Hose Type - Polyester Single Jacket (Mildew Resistant)
  • Color - Yellow
  • Liner - Thermoplastic Polyurethane (TPU)
  • Approximate Width Laying Flat - 1 3/4 inches
  • Service Pressure - 300 PSI
  • Proof Test Pressure - 600 PSI
  • Burst Test Pressure - 900 PSI

1" Hose Male Couplings

  • Inside diameter of a male coupling - 1 inch
  • Outside diameter of a male NH / NST coupling - 1 3/8 inches (8 Threads per inch)
  • Outside diameter a male NPSH or NPT coupling - 1 5/16 inches (11.5 Threads per inch)


Limited 1-Year Warranty

We will replace any fire hose with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

Fire hoses purchased for use at Fire Training Facilities will have a 90-day Manufacturer Defect warranty only.

Upon receipt of the returned goods, hoses will be subject to inspection and testing.

Should it be determined that the hose is covered by warranty, it will be repaired or replaced.

Connections

  • The female side of a NH / NST coupling will only connect to a male NH / NST connection
  • The male side of a NH / NST coupling will only connect to a female NH / NST connection
  • The female side of a NPSH coupling will only connect to a male NPT pipe or a male NPSH connection
  • The male side of a NPSH coupling will only connect to a female NPSH connection. It will NOT thread into a female NPT pipe. For example, a male NPSH coupling will NOT thread into a female metal or pvc pipe.
  • The female side of a garden hose will only connect to a male garden hose connection.
  • The male side of a garden hose will only connect to a female garden hose connection.

The most common thread type in use by fire departments today is NST or National Standard Thread. NST also goes by the initials NH or National Hose. It can even be referred to as NHT or National Hose Thread but NST or NH is more common these days. NH = NST
