Orange 2 1/2" x 25' Mil-Spec Hose (Brass NH Couplings)

  • Orange 2 1/2" x 25' Mil-Spec Hose (Brass NH Couplings)
1 6
Price: $442.94
$0.00 $442.94
Sale Sold out

Stock Level: 0

Product Status: Special Order

When Will it Ship: Contact for Lead Time

Shipping Cost: Free Shipping

Shipping Transit Time: 2 to 5 Business Days

Eligible for Express Shipping: No

Stock Level Updated: Dec 26, 2024


Item Number: 25D6MS25B
Weight: 15.0 lb

View full details

Description

Our 2 1/2 inch Made in USA double jacket firefighting hose meets and exceeds all NFPA 1961 standards. Hose is stenciled and constructed to meet Mil Spec Mil-H-24606B used by the Navy, Coast Guard and other Military branches. This 24606 hose features 2 1/2 inch brass couplings and orange abrasion impregnation.

This hose is constructed of an EPDM synthetic rubber tube and a double layer of 100% polyester woven jackets. The rubber lining is a single-ply extruded tube of synthetic EPDM compounded to resist ozone. Double jacket refers to the second layer polyester covering woven from staple polyester yarn added for increased abrasion resistance. NH /NST threads are standard.

Mil-Spec Hoses are stenciled to include

  • MIL-H24606B
  • Size and length of hose
  • Service test pressure
  • Month and year
  • Manufacturer

Note: The most common 2 1/2 inch Mil Spec hose is coupled with NH / NST threads. Please verify thread type before ordering.

Test Ratings (Water Only With Expansion Ring Couplings)

  • 300 PSI Service Pressure (A 3-minute hydrostatic test conducted by users on in-service hose to determine suitability for continued service)
  • 600 PSI Proof Test Pressure (A pressure equal to a least two times the service test pressure)
  • 900 PSI Burst Test Pressure

Applications

  • Navy
  • US Coast Guard (USCG)
  • Military Branches

REF/PN - MIL-H-24606

NSN - 4210000325002 or 4210-00-032-5002

CAGE Code - 81349



Specifications

  • Made in USA
  • Hose Size: 2 1/2 inches (Inside Diameter)
  • Hose Length: 25 feet (Approximately)
  • Male Coupling: Brass 2 1/2 inch NH / NST
  • Swivel Female Coupling: Brass 2 1/2 inch NH / NST
  • The Female Coupling Will Only Connect to a Male 2 1/2 inch NH / NST
  • Compatible Nozzle: 2 1/2 inch NH NST only
  • Hose Type: Polyester Double Jacket (Mildew Resistant)
  • Color: Orange
  • Liner: EPDM Rubber
  • Approximate Width Laying Flat: 4 1/4 inches
  • Service Pressure: 300 PSI
  • Proof Test Pressure: 600 PSI
  • Burst Test Pressure: 900 PSI
  • UL Listed and ZZ-H-451-G Compliant

2 1/2" Hose Male Couplings

  • Inside diameter of a male coupling: 2 1/2 inches
  • Outside diameter of a male NH / NST coupling: 3 1/16 inches (7.5 Threads per inch)
  • Outside diameter a male NPSH or NPT coupling: 2 7/8 inches (8 Threads per inch)

Download Spec Sheet

Help Me Connect

Connections

  • The female side of a NH / NST coupling will only connect to a male NH / NST connection
  • The male side of a NH / NST coupling will only connect to a female NH / NST connection
  • The female side of a NPSH coupling will only connect to a male NPT pipe or a male NPSH connection
  • The male side of a NPSH coupling will only connect to a female NPSH connection. It will NOT thread into a female NPT pipe. For example, a male NPSH coupling will NOT thread into a female metal or pvc pipe.

The most common thread type in use by fire departments today is NST or National Standard Thread. NST also goes by the initials NH or National Hose. It can even be referred to as NHT or National Hose Thread but NST or NH is more common these days. NH = NST

Warranty Information

Limited 10-Year Warranty

We will replace any fire hose with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

Fire hoses purchased for use at Fire Training Facilities will have a 90-day Manufacturer Defect warranty only.

Upon receipt of the returned goods, hoses will be subject to inspection and testing.

Should it be determined that the hose is covered by warranty, it will be repaired or replaced.
